What is aeroTAP evo?
aeroTAP evo is an interface system for operating a computer without using a mouse, keyboard, or touch panel. The operator can operate using the palm or fingertips.
Since there is nothing to touch, there are advantages such as "Hygienic", "Operable from a distance". and "No damage to equipment".
aeroTAP evo works with any existing application. It enables users to interact with simple gestures without development and modification.
The Main Feature
- Existing applications and contents can be made touchless directly
You can operate with your palm by just connecting the camera and runing aeroTAP. You do not have to develop a program to make your contents touchless.
- Minimum CPU resource consumption
aeroTAP 3D USB camera works with USB 2.0. aeroTAP evo does not require-high end PCs because it uses a low consumption algorithm that does not use GPU or multi-core.
For this reason, you can even make tablets or Stick PCs touchless.
- Assist feature (virtual button)
This is a feature that makes palm operation easier and it is fully customizable. It will enable the operation of an application by using just your palm.
Virtual button includes hybrid virtual button, virtual scroll bar, virtual mouse button, virtual button, and many other types.
aeroTAP evo can be used for Medical, E-Signage, Ticketing machine and others for enabling touchless operation.
Others Features
- Operations made touchless and quick
Operations are easy and quick using virtual buttons and virtual scroll bars, sometimes making the operation faster than using a mouse/keyboard.
- Various customization
You can customize to a touchless interface according to the contents used.
- Plug and Play
After the first start-up of aeroTAP, you can make it run just by inserting the aeroTAP 3D USB camera.
- Supports a wide range of distance
Distance for palm operation can be adjusted from 40cm to 3m.
For more information about the operation distance and the settings, see aeroTAP Technical Information -Appropriate operation distance and aeroTAP settings section.
Functions
Palm tracking
- Touchless operation with the palm
- Operation assistant feature (virtual button)
Nearest Object Tracking Mode (touchless)
- Touchless operation with the fingertip, close range operation
Virtual Touch Screen (for integretion)
- Generate virtual touch screen (close ranges)
- Generate mouse click and touch event
- Generate hover surface
Tracking Engine
- Palm tracking mode
- Nearest object tracking mode (environment dependent)
Emulation
- Mouse, Keyboard
- Touch events (only for Windows 10)
Environment Detection
- It detects whether the operator exists or not
- Blackout detection (no light)
What is touchless?
There are 2 methods for touchless operations. One way is called Gesture Interface method, which uses the body, hands and fingers. The other is non-contact method, which you operate physical buttons or touch screens without actual contacts aeroTAP evo is designed to support all kinds of touchless operation. Therefore, it implements both Palm tracking (gesture interface method) and Virtual touch screen (non-contact method).o.
Reinventing Touchless...
